The Sensaphone SCADA 3000

SCADA 3000: The fully integrated control system.
With the SCADA 3000, the high cost of control is history!

SCADA group

SCADA 3000 provides everything you need--from software to modules--in one comprehensive package.
Flexible Communication
: Use standard data radio, ordinary phone lines, or a mix of both.
Built-in Alarm Notification: Alarm reports using custom voice, numeric pager, alphanumeric pager, fax, or E-mail.
Built-In Data Logging: Time-stamped data. The SCADA 3000 package includes software for data logging radio network applications, too.
Powerful Programming Options: Ladder, C-Programming, PID Functions, and even remote access programming.
Flexible Power Sources: with intelligent battery charging, safe battery cut-off and even built-in support for solar power.
Live Web Pages: generate reports as web pages on your internet or intranet site, with customizable features and programmable time intervals.

Free, powerful 32-bit SCADA software with critical built-in features:

  • Ladder Editor: the preferred language for control functions. SCADA 3000 supports up to 128 FPU variables and 4096 bits organized as 255 16-bit words. It uses standard Ladder elements and instructions.

Ladder screenLive Web Page link

  • C-Program Editor: for sophisticated control programming, define up to 1024 variables with up to 15 characters per variable name. Run the C program synchronously or asynchronously with the ladder program.
  • PID Programming: eight built-in programmable PID control algorithms allow the SCADA 3000 to operate as a feedback controller.
  • Alarm Functions: Alarm up to 64 events from any input, output variable or value that has a UAF. Program recognition time, high and low limits, and reset time. Record custom voice messages for any alarm.
  • Real Time Screen Builder: Create a custom screen to show the real-time status of I/O values and process variables. Use standard graphical representations of your processes.

RealTime editor

  • Data Logging: Store up to 50,000 samples from up to 128 I/O points or system variables (UAFs). Date and time stamp. Query multiple units and display the information in grid format.
  • Communications Manager: Communicate by data radio to keep your PC in constant communication with all connected RTUs, or by phone line if you want to receive information from RTUs on an as-needed basis. Configure up to four serial ports for radio and/or phone communication.

Hardware Configuration

16 Universal Inputs: Contact closures, Thermistors, 4-20mA Analog, 0-5V Analog, Run time accumulator
8 Outputs: Latching 2 amp relays, LED status indicators
2 RS232 Ports: Local programming, Data radio communications; RJ11 Phone interface
LCD: 4x20 character scrolling display; user-customized content for local viewing.


Data Logging: User-programmable, built-in data storage for I/O points or calculated values.
Event Logging: Internal tracking of alarms and events
Ladder Logic Programming: for true PLC-type control; visual ladder editor standard in the software package.
C-Programming: Built-in C-compiler, which can run independent of ladder program.
PID: Eight PID loops built into the internal programming. Any I/O points may be used for PID calculations.
Web Page Generation: Software to upload I/O status and alarm data as a customizable web page to the URL of your choice.
AGA Gas Flow Calculation


Input/Output: expandable to 144 points, with these additional SCADA 3000 Modules:

  • Universal Inputs (identical to the 16 built into the main unit)
  • High Speed Pulse Count Inputs (up to 10kHz)
  • Thermocouple Inputs (Types J, K, R, S, T and E)
  • Relay Outputs
  • Analog Outputs (4-20mA)
  • Annunciator

Communication: Phone modem; voice module.
Power Supply: Hard-wired for 110 or 220 VAC; Plug-in for 110 or 220 VAC; standard or extended battery backup.


Included in purchase price, the software package provides the capability to program units, develop ladder and C programs, retrieve and analyze data and event logs, and print reports. Automatically polls for data via phone or radio; uses customized screen graphics; provides true 32-bit code for WindowsTM 95, 98, ME, NT and 2000.

Warranty & Compliance

A 3-year comprehensive warranty, and unlimited technical support available by phone, E-mail and internet.
The Sensaphone SCADA 3000 is manufactured in the USA.
